Bard Synthesizers - Vacuform

DESCRIPTION

Vacuform is a 12 dB multimode filter utilizing vacuum tubes as active elements. It is intended to generate filtered sound with complex relations and control parameter interdependencies, adding more details to the sound compared to common transistorized designs.

FEATURES

◯ Discrete, vacuum tube multimode filter

◯ Simultaneous lowpass, bandpass and highpass inputs

◯ Cutoff frequency manually controlled or via two CV inputs, from which one can be attenuverted

◯ Resonance amount manually controlled or via attenuated CV input; Can be set to oscillation

◯ AC-Coupled Output with attenuation

◯ Widely varying degree of inherent soft saturation

◯ Resonant output waveform dependent on input signal anplitude

DETAILS

Eurorack synth compatible
16HP, 42mm deep
Weight: 294g
Current draw: +12V 24mA; -12V 24mA; +5V (startup) 1550mA; +5V (running) 890mA
